C Operators

In a C program, data items (variables and constants) can be arithmetically manipulated using operators. An operator is a symbol that tells the computer to perform certain mathematical or logical manipulation on data stored in variables. The variables that are operated are termed as operands.

C operators can be classified into a number of categories. They include:

1.                                   Arithmetic operators

2.                               Relational operators

3.        Logical operators

4.                                   Assignment operators

5.                                 Increment and decrement operators

6.                             Conditional operators

7.                                bit-wise operators

8.                                   Special operators

Arithmetic Operators

Arithmetic operators work on numeric type of operands. C provides all the basic arithmetic operators.
There are five arithmetic operators in C.

___________ Operator____________ Purpose___________________

+                                    Addition

-                                    Subtraction

*                                    Multiplication

/                                     Division

                 %                                   Remainder after integer division

The division operator (/) requires the second operand to be non-zero, though the operands need not be integers.   When an integer is divided by another integer, the ,Result is also an integer. In such instances the division is termed as integer division. Consider the following:

int ;x;
x= 10;

What do you expect the value of x/4 to be? If you guessed 2.5, you are wrong. The result is of course 2.5 however, since it is integer division, 2.5 will be truncated to 2. In case you wish to get the correct value you make this division a float type as x/4.0.
The % operator is known as modulus operator. It produces the remainder after the division of two operands. The second operand must be non-zero.
Rest all other operators work in their normal arithmetic way. Normal BODMAS rules are also applicable to these arithmetic operators.

Relational operator

Relational operator is used to compare two operands to see whether they are equal to each other, unequal, or one is greater or lesser than the other.

While the operands can be variables, constants or expressions, the result is always a numeric value equivalent to either true or false. As mentioned earlier a non-zero result indicates true and zero indicates false. C language provides six relational operators.

= =                                      equal to

! =                                       not equal to

<                                         less than

<=                                       less than or equal to

>                                         greater than

> =                                      greater than or equal to

A simple relation contains only one relational expression and takes the following form:

<ae-l> <relational operator> <ae-2>

<ae-l> and <ae-2>' are arithmetic expressions, which may be constants, variables or combination of these. The value of the relational operator is either 1 or 0. If the relation is true, result is 1 otherwise it is 0.

e.g.:             Expressions                 Result

    6.3 < = 15                        True

2.5 < -2                          False

-10> =0                          False

                               10 <8+3                        True

Logical Operators

More than one relational expression can be combined to form a single compound relational expression using logical operators. Logical operators are used to combine two or more relational expressions. C provides three logical operators. A compound relation behaves identically producing either true or false value.

Operator           Meaning               Result

&&                  Logical AND          True if both the operands are true

Logical OR            True if both the operands are true

!                      Logical NOT          True if the operand is false and vice versa

e.g.:      1.   (age > 50 && weight < 80) will evaluate to true if age is more than 50 and also weight is less than 80. Otherwise it will evaluate to false.

2.             ( a < 0   ch = = 'a') will evaluate to true if a is less than 0 while ch is equal to 'a', false otherwise.

3.             (.! (a < 0)) will evaluate to true if a is greater than or equal to 0, false otherwise.

Assignment Operators

Assignment operators are used to store the result of an expression to a variable. The most commonly used assignment operator is (=). Be careful not to mistake assignment operator (=) for mathematical equality operator which is indicated by the same symbol.

An expression with assignment operator is of the following form:

 <identifier>  =   <expression>;

When this statement is executed, <expression> is evaluated and the value is stored in the <identifier>. Note that data type of both the sides should be either the same or compatible to each other.

Let us consider the following program that illustrates usage of assignment operator in C language.

#include <stdio.h>

main(   )

{

int  i ;

i   =   5;

printf   ("%d",   i);

i  =  i   +   10;

printf   ("n%d",   i);

}

Output will be:     5

15

In this program the current value stored in variable i is 5. Thus, while executing i = i+10;, the right hand side will be evaluated to give a value 15. This value will then be assigned to the left hand side. As a result, the current value of I after execution of this statement will become 15.

Increment and Decrement Operators

C has two very useful operators ++ and — called increment and decrement operators respectively. These are generally not found in other languages. These operators are unary operators as they require only one operand. The operands must be a variable

name and not a constant.

The increment operator ('++) adds one to the current value of the operand and stores the result back into the operand, while the decrement operator (—) subtracts one from the operand and stores the decremented value back into the operand.

There are two different forms of increment and decrement operators. When they are used before the operand, it is termed as prefix, while when used after the operand, they are termed as postfix operators.

e.g.:    int i   = 5;

i ++;

++ i;

-- i;

-- i;

When used in an isolated C statement, both prefix and postfix operators have the same effect, but when they are used in expressions, each of them has a different effect.

In expressions, postfix operator uses the current value and then increments/decrements while in the prefix form the value is incremented/decremented first and then used in the expression. Consider the following examples:

e.g:   b = a   ++;

 this is postfix increment expression. This statement is equivalent to:

{b =  a;

a = a+1;}

e.g.       b  =   -   -   a;

this is prefix decrement expression. This statement is equivalent to:

{   a=   a-1; b =   a;   }

Consider the following C program that illustrates the usage of postfix and prefix increment operators.

#include<stdio. h>

main( ) {

int a = 10; b = 0;

a++ ;

printf ("\n a = %d", a);

b = ++a;

printf ("\n a = % d, b = % d",a, b) ;

b = a++;

printf ("\n a = % d, b 1 % d", a, b);

     }

output:   a =11

a = 12 b = 12 a = 13 b = 12

Bitwise Operators

You know that a numeric value is stored in a variable in binary form.Bitwise operators are used for manipulation of data at bit level. These operators are used for testing the bits, or shifting them right or left. Bitwise operators are applicable to integer data types only. A list of different bit wise operators available in C language and their corresponding meaning is presented below:

Some Bit wise Operators

__________ Operator__________ Meaning______________________

&                             Bitwise Logical AND

|                              Bitwise Logical OR

Bitwise Logical XOR

<<                            Left shift

> >                           Right shift

~                             One's complement

 (Bit-wise OR)                     :binary operator takes two operands of int

type and performs bit-wise OR operation. With assumption that int size is 8-bits:

int a = 5;       [binary : 0000 0101]

int b = 9;       [binary: 0000 1001]

a l b yields      [binary: 0000 1101]

& (Bit-wise AND)                  :binary operator takes two operands of int

type and performs bit-wise AND operation. With same assumption on int size as above:

int a = 5;       [binary : 0000 0101]

int b = 9;       [binary: 0000 1001]

a & b yields     [binary: 0000 0001 ]

 ^ (Bit-wise Logical XOR)       :XOR gives 1 if only one of the operand is 1

             else 0. With same assumption on int size as

above:

int a = 5;        [binary: 0000 0101]

int b = 9;        [binary 10000 1001 ]

a ^ b yields        [binary: 0000 1100]

<<(Shift left)                         :This  operator  shifts  the bits  towards left

padding the space with 0 by given integer times.

int a = 5;        [binary: 0000 0101]

a «3 yields       [binary : 0010 1000]


» (Shift right)                           :This operator shifts the bits towards right

padding the space with 0.

                                   int a = 5;         [binary : 0000 0101]

a » 3 yields       [binary: 0000 0000]

~ (one's complement operator)      :It is a uniary operator that causes the bits of

its operand to be inverted so that 1 becomes 0 and vice-veria. The opearator must always precede the operand and must be integer type of all sizes. Assuming that int type is of 1 byte size:

inr a = 5;        [binary: 0000 0101]

~a;                 [binary: 1111 1010]

c programmming online,basic of c language,structure of c programming,c language statements,Compiling a C Program,Pseudo Codes in c,basis data type in c ,variables in C Program,constants in C Program,c operators in C Program,special operators in C ,Decision Making,Branching & Looping in C Program,if statement in C Program,for loop in C Program

Constants in C

The quantities involved in programming are not all of variable types alone. Some of the quantities do not change their values as variables do. They are called constants.
A constant is an entity with fixed value that does not change. It can be stored at a location in the memory of the computer and can be referenced through that memory address. There are four basic types of constants in C, viz. integer constants, floating- point constants, character constants and string constants. Composite types may also have constants.
Integer and floating-point constants represent numbers. They are often referred to collectively as numeric-type constants.
C imposes the following rules while creating a numeric constant type data item:
Commas and blank spaces cannot be included within the constants
• The constant can be preceded by a minus(-) sign if desired.
• Value of a constant cannot exceed specified maximum and minimum bounds.
For each type of constant, these bounds will vary from one C-compiler to
another.
Constants are the fixed values that remain, unchanged during the execution of a program and are used in assignment statements Constants can also be stored in variables.
The declaration for a constant in C language takes the following form:
const datatype var_name = value;

Exapmle: const float pi = 22/7;

This declaration defines a constant named pi whose value remains 22/7 throughout the program in which it is defined.
C language facilitates five different types of constants.
1. Character
2. Integer
3. Real
4. String
5. Logical
Character Constants: A character constant consists of a single character, single digit, or a single special symbol enclosed within a pair of single inverted commas. The maximum length of a character constant is one character.
Ex.:'a' is a character constant
Ex.: 'd' is a character constant
Ex.: 'P' is a character constant
Ex.: '7' is a character constant
Ex.: '*' is a character constant
Integer Constants: An integer constant refers to a sequence of digits and has a numeric value. There are three types of integers in C language: decimal, octal, hexadecimal.
Decimal integers : 1,56, 7657,-34 etc.
Octal integers : 076, -076,05 etc. (preceded by zero, 0)
Hexadecimal integers : 0x56, -0x5D etc. (preceded by zero, Ox)
No commas or blanks are allowed in integer constants.
Real or floating point Constants: A number with a decimal point and an optional preceding sign represents a real constant.
Exapmle: 34.8, -655.33, .2, -.56, 7.
Note that 7 is an integer while 7. or 7.0 is real.
Another notation (called scientific notation) for real constants consists of three parts:
i) A sign (+ or 0) preceding the number portion (optional).
ii) A number portion
iii) An exponent portion following the number portion (optional). It
starts with E or e followed by an integer. Which may or may not
be preceded by a sign.
Example:

Valid Representations	Invalid Representations
+ . 72	12 (no decimal)
+ . 72	12 (no decimal)
+ 72.	7.6 E + 2.2(non integer exponent)
+ 7.6 E + 2	1.2 E9229892(very large exponent)
24.4e-5

String Constants: A string constant is a sequence of one or more characters enclosed with in a pair of double quotes (" "). If a single character is enclosed within a pair of double quotes, it will also be interpreted as a string constant and not a character constant.
Exapmle:
1. "Welcome To C Programming \ n"
2. "a"
Actually, a string is an array of characters terminated by a NULL character. Thus, "a" is a string consisting of two characters, viz. 'a' and NULL('\0')
Logical Constants:A logical constant can have either true value or false value. In C, a non zero value is treated as true while 0 is treated as false.

Variables in C

A variable is an entity whose value can change during program execution. A variable can be thought of as a symbolic representation of address of the memory space where values can be stored, accessed and changed. A specific location or address in the memory is allocated for each variable and the value of that variable is stored in that location.

Each variable has a name, data-type, size, and the value it stores. All the variables must have their type indicated so that the compiler can record all the necessary information about them, generate the appropriate code during translation and allocating required space in memory.

Every programming language has its own set of rules that must be observed while
writing the names of variables. If the rules are not followed, the compiler reports
compilation error. Rules for Constructing Variable Name in C language are listed
below:

a. Variable name may be a combination of alphabets, digits or underscores.
Sometimes, an additional constraint on the number of characters in the
name is imposed by compilers in which case its length should not exceed
8 characters.
b. First character must be an alphabet or an underscore (_).
c. No commas or blank spaces are allowed in a variable name.
d. Among the special symbols, only underscore can be used in a variable name.
e.g.: emp_age, item_4, etc.
e. No word, having a reserved meaning in C can be used for variable name.

Note that C language is a case-sensitive language which differentiates between lower case and upper case. Thus, CAT is different from Cat, cAT, CaT. Although any word complying with the rules cited above can be used as the variable name, it is advised tha you create variable names that have some meaning. Thus, you may chose sum as the variable name for storing sum of numbers rather than choosing X.

Type Declaration

C language is strongly typed language, meaning that all the variables must be declared before their use. Declaration does two things:
It tells the compiler what the variable name is.
It specifies what type of data the variable will hold.
In C language, a variable declaration has the form:

Here is one of the valid data types (e.g. int, float, char, etc.). List-of-variables is a comma-separated list of identifiers representing the program variables.
e.g.-
a. int i, j, k; //creates integer variables i,j and K
b. char ch; //creates a character type variable ch
Once variable has been declared in the above manner, the compiler creates a space in the memory and attaches the given name to this space This variable can now be used in the program.
A value is stored in a variable using assignment operation. Assignment is of the form:
Variable-name = ; Obviously, before assignment, the variable must be declared. e.g.: int i, j;
j = 5; i = 0 ;
C also allows assignment of a value to a variable at the time of declaration. It takes the following form:

e.g. : int I = 5;
This declaration not only creates an interior type variable I, but also stores a value 5 at the same time.
The process of assigning initial values to the variable is known as initialization. More than one variable can be initialized in one statement using multiple assignment operators.
e.g.: i. int i = 5, ]=3;
ii . int j, m; j = m = 2; However, there is an exception worth noting. Consider the following example:
int i, j = 2, k ; The assignments will be made as follows: i = 0 j = 2
k =1063 (a garbage value, unutilized) Let us consider some of programming examples to illustrate the matter further.
Example 2
/* Example of assignments */ /'* declaration */
int al, bl; /* declaration & assignment */
int var = 5;
int a, b 1 6, c;
/* declaration & multiple" assignment */
int p, q, r, s;
p = q=r = s = 5;

values stored in various variables are:
var = 5
a = 0, b = 6
c = garbage value
p = 5, q = 5, r = 5, s = 5
